Compact-Speisesystem UAS 144 BN 268038
Kathrein; Rosenheim
- Country
- Germany
- Manufacturer / Brand
- Kathrein; Rosenheim
- Year
- 1994 ??
- Category
- Antenna (Aerial) or Coupler
- Radiomuseum.org ID
- 259215
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- RF Converter/Adapter (not voltage converter)
- Wave bands
- SAT-IF
- Power type and voltage
- Powered by external power supply or a main unit. / DC 12-19 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Compact-Speisesystem UAS 144 BN 268038 - Kathrein; Rosenheim
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 180 x 44 x 97 mm / 7.1 x 1.7 x 3.8 inch
- Notes
-
LNC, 10,7-11,7 GHz,
Verstärkung 50 dB, LO 9,750 GHz.
Vert.12-15,5V, hor. 16-19V.
- Net weight (2.2 lb = 1 kg)
- 1.2 kg / 2 lb 10.3 oz (2.643 lb)
- Mentioned in
- -- Original prospect or advert
- Author
- Model page created by a member from D. See "Data change" for further contributors.
