• Country
• France

• Manufacturer / Brand
• La Radiophonie Francaise (Inno-Radio); Paris

• Year
• 1940 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 123239

• Number of Tubes
• 6

• Valves / Tubes
• 6E8G 6M7MG 6H8MG 6V6G 6AF7 5Y4S

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Inconnu - Unknown 1 - La Radiophonie Francaise Inno-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 513 x 357 x 290 mm / 20.2 x 14.1 x 11.4 inch

• Net weight (2.2 lb = 1 kg)
• 9.3 kg / 20 lb 7.8 oz (20.485 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.
