- Country
- France
- Manufacturer / Brand
- Limousin, C.; Paris
- Year
- 1949 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 322571
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 14 cm = 5.5 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: RM5 - Limousin, C.; Paris
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 420 x 290 x 200 mm / 16.5 x 11.4 x 7.9 inch
- Net weight (2.2 lb = 1 kg)
- 6.6 kg / 14 lb 8.6 oz (14.537 lb)
- Author
- Model page created by Philippe Harang. See "Data change" for further contributors.
- Other Models
-
Here you find 3 models, 1 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Limousin, C.; Paris
