Lincoln Luxe 60
Lincoln (brand)
- Country
- France
- Manufacturer / Brand
- Lincoln (brand)
- Year
- 1934 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 189019
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 135 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Lincoln Luxe 60 - Lincoln brand
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 310 x 230 x 180 mm / 12.2 x 9.1 x 7.1 inch
- Notes
-
Malgré les lampes typiquement employées dans les modèles tous courants, la présence d'un auto-transformateur reduit son utilisation au secteur alternatif (source: doctsf). L'indication de voltage de réseau uniquement 110 Volt peut être incomplète.
- Literature/Schematics (2)
- Le grand livre de la TSF (Doctsf Ref. 3667, comme Lincoln Luxe)
- Author
- Model page created by Philippe Ragot. See "Data change" for further contributors.
