• Country
• France

• Manufacturer / Brand
• LRD, La Radio de Demain - voir REP

• Year
• 1949 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 241160

• Number of Tubes
• 6

• Valves / Tubes
• 6E8MG 6M7MG 6H8MG 25L6GT 6AF7G 25Z6GT

• Main principle
• Superheterodyne (common); ZF/IF 487 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Inconnu - Unknown 1 - LRD, La Radio de Demain - voir

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 490 x 315 x 260 mm / 19.3 x 12.4 x 10.2 inch

• Notes

• Dial lamps: 2x 8045D (6,3V/0,32A).

• Author
• Model page created by Antonio Martins-Pais. See "Data change" for further contributors.

• Other Models

• Here you find 2 models, 2 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from LRD, La Radio de Demain - voir REP
