1560W
Luxor Radio AB; Motala
- Country
- Sweden
- Manufacturer / Brand
- Luxor Radio AB; Motala
- Year
- 1939 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 18183
-
- alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- from Radiomuseum.org
- Model: 1560W - Luxor Radio AB; Motala
- External source of data
- E. Erb 3-907007-36-0
- Circuit diagram reference
- Die «Thali Schemasammlung» führt das Modell.
