• Country
• Sweden

• Manufacturer / Brand
• Luxor Radio AB; Motala

• Year
• 1949

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 200147

• • alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)

• Number of Tubes
• 5

• Valves / Tubes
• 6J6 6BA6 6AT6 6V6 6X5

• Main principle
• Superheterodyne (common); ZF/IF 474 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 150; 220; 250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16.5 cm = 6.5 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: 193RW - Luxor Radio AB; Motala

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 495 x 310 x 225 mm / 19.5 x 12.2 x 8.9 inch

• Notes
• Dial lamps: 2x 6,5V/0,3A.

• Source of data
• - - Data from my own collection

• Author
• Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
