• Country
• Sweden

• Manufacturer / Brand
• Luxor Radio AB; Motala

• Year
• 1930 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 316967

• • alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)

• Number of Tubes
• 4

• Valves / Tubes
• E438 Arcotron201 L416D 506

• Main principle
• TRF with regeneration

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: 4 rör mottagare unknown - Luxor Radio AB; Motala

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 240 x 150 x 155 mm / 9.4 x 5.9 x 6.1 inch

• Author
• Model page created by Torbjörn Hansson. See "Data change" for further contributors.

• Other Models

• Here you find 405 models, 314 with images and 147 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
