664-DW
Luxor Radio AB; Motala
- Country
- Sweden
- Manufacturer / Brand
- Luxor Radio AB; Motala
- Year
- 1934 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 196657
-
- alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)
- Number of Tubes
- 6
- Valves / Tubes
- AK1 AF2 AB1 E499 or REN914 or AR495 E443H or RES964 or PP4101 U12 or RGN1064 or PV4100
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 100-150; 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 664-DW - Luxor Radio AB; Motala
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 395 x 425 x 225 mm / 15.6 x 16.7 x 8.9 inch
- Notes
- Netzspannung umschaltbar in 10 V-stufen innerhalb die angegebene Bereiche. Glimmlampe zur Abstimmanzeige.
- Source of data
- - - Data from my own collection
- Author
- Model page created by Torbjörn Forsman. See "Data change" for further contributors.
