825AWL
Luxor Radio AB; Motala
- Country
- Sweden
- Manufacturer / Brand
- Luxor Radio AB; Motala
- Year
- 1935 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 338849
-
- alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)
- Number of Tubes
- 5
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- AC/DC-set / 110; 127; 140; 210; 225; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 825AWL - Luxor Radio AB; Motala
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 390 x 310 x 200 mm / 15.4 x 12.2 x 7.9 inch
- Notes
-
See also Luxor models 825W, 825WL and 825AW.
Model 825AWL and 825WL seem the same, hoewever, model 825AWL is equipped with a gramophone input.
- Author
- Model page created by Wilhelm Siepe. See "Data change" for further contributors.
