Empire 1817W
Luxor Radio AB; Motala
- Country
- Sweden
- Manufacturer / Brand
- Luxor Radio AB; Motala
- Year
- 1958 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 149326
-
- alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)
Original Prospekt
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Number of Transistors
- Semiconductors
- Selengleichrichter
- Main principle
- Superheterodyne (common); ZF/IF 462/10700 kHz
- Tuned circuits
- 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 150; 220; 250 Volt
- Loudspeaker
- 4 Loudspeakers
- Power out
- 8 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Empire 1817W - Luxor Radio AB; Motala
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 1010 x 820 x 430 mm / 39.8 x 32.3 x 16.9 inch
- Notes
-
Wave bands:
- MW: 190-572 m
- LW: 690-2000 m
- SW1: 11.3-21.6 m
- SW2: 21.4-63.5 m
- SW3: 63.5-217 m
- FM: 86-108 MHz.
Cabinet is built in mahogany with intarsia decoration in high quality.
Record changer: Luxor RT103 or Luxor RTW78A (made at RT Verken Sävsjö Sweden).
Four Luxor Briljant loudspeakers, all of the same diameter, 20 cm, type P5B-8R625/110, 8 ohm.
Ferrite antenna, controlled from the front dial. At the end of rotation a separate antenna connection for LW and MW is switched in.
- Net weight (2.2 lb = 1 kg)
- 58 kg / 127 lb 12.1 oz (127.753 lb)
- Price in first year of sale
- 1,750.00 SEK
- Mentioned in
- The "Luxor-programmet No5/1959"
- Author
- Model page created by Jörgen Svensson. See "Data change" for further contributors.
