Compact Disc Player FD3030SL01

Philips Magnavox (brand); Knoxville, TN

Data
Forum
Pictures
Collections

  • Year
  • 1983 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 309469

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact Disc Player FD3030SL01 - Philips Magnavox brand;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 420 x 88 x 315 mm / 16.5 x 3.5 x 12.4 inch
  • Notes

  • A first generation compact disc player with a Philips CDM-0 laser transport mechanism, 2 x TDA1540D 14 bit DACs and an SAA7030 4 times oversampling digital filter.

    Specification
    Frequency Range ..............:  20Hz-20kHz ± 0.05dB
    Signal to Noise Ratio .........:  ≥ 90dB (20Hz-20kHz)
    Channel separation ...........:  ≥ 86dB (20Hz-20kHz)
    Total Harmonic Distortion...:  ≤ 0.01%
    Intermodulation Distortion .:  ≤ 0.005%

    Versions/Power Requirements :
    120 V AC 60Hz

    Same as the Philips CD303 model with Magnavox labels for the US market.

    Made in Belgium

  • Net weight (2.2 lb = 1 kg)
  • 8 kg / 17 lb 9.9 oz (17.621 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Service manual for the Philips CD303 dated 1983-11-17)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
