• Country
• France

• Manufacturer / Brand
• Manufrance, Manufacture Française (MF, M.F.); Saint-Étienne

• Year
• 1939 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 73753

• Number of Tubes
• 7

• Valves / Tubes
• 6A8 6K7 6H6 ME6 6F5 6V6 5Y3

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 18 cm = 7.1 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: BA50P - Manufrance, Manufacture

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 570 x 335 x 270 mm / 22.4 x 13.2 x 10.6 inch

• Notes
• Abnehmbare Beine zur Verwendung als Standgerät.

• Author
• Model page created by Steffen Thies. See "Data change" for further contributors.

• Other Models

• Here you find 194 models, 180 with images and 10 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Manufrance, Manufacture Française (MF, M.F.); Saint-Étienne
