• Country
• France

• Manufacturer / Brand
• Marquett-Radio (Cambridge), Éts. Marcel Auvray; Rouen, Paris

• Year
• 1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 68693

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH42 EAF42 EF41 EL42 EM34 GZ40

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110-245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: Orient 678-6G [6 gammes] - Marquett-Radio Cambridge, Éts.

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 450 x 320 x 230 mm / 17.7 x 12.6 x 9.1 inch

• Notes

• 6 gammes d'ondes. Contre-réaction type plaque à plaque.

  Coffret matière plastique imitation bois.

• External source of data
• Serge Laffont/Martin Renoth

• Other Models

• Here you find 58 models, 54 with images and 17 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Marquett-Radio (Cambridge), Éts. Marcel Auvray; Rouen, Paris
