- Country
- France
- Manufacturer / Brand
- Martin, V.; Paris, Courbevoie
- Year
- 1933 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 249514
- Number of Tubes
- 6
- Valves / Tubes
- unknown_Tube EY624 EY635 EY624 EY627 unknown_Tube
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 24.3 cm = 9.6 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 255 - Martin, V.; Paris, Courbevoie
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 430 x 500 x 320 mm / 16.9 x 19.7 x 12.6 inch
- Notes
-
Le numéro de type 255 est incertain.
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Author
- Model page created by Manfred Rathgeb. See "Data change" for further contributors.
