All Transistor M873T
Médiator; Paris
- Country
- France
- Manufacturer / Brand
- Médiator; Paris
- Year
- 1961/1962
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 287552
Modèle Atlantic. Aus den Serviceunterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Dry Batteries / 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Power out
- 0.42 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: All Transistor M873T - Médiator; Paris
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 265 x 170 x 80 mm / 10.4 x 6.7 x 3.1 inch
- Notes
-
3 gammes d'ondes : OC de 16.4 à 5.9 MHz, PO de 1620 à 520 kHz, et GO de 265 à 150 kHz. Clavier 5 touches. Cadre ferrocapteur de 200 mm, antenne télescopique de 70 cm. HP Z = 19 Ω. Prise antenne-voiture.
Coffret polystyrène, deux coloris : jaune, vert. Poignée ivoire démontable.
Équivalent au Atlantic A873T.
- Net weight (2.2 lb = 1 kg)
- 1.6 kg / 3 lb 8.4 oz (3.524 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
