- Country
- Austria
- Manufacturer / Brand
- Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
- Year
- 1974
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 104855
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 21
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz; 6 AF stage(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 110; 230 / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: MC4500 Automatic - Minerva-Radio Radiola-
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 360 x 200 x 95 inch / 9144 x 5080 x 2413 mm
- Notes
-
Bei Netzbetrieb steht der Trafo ständig unter Spannung, falls man nicht das Netzkabel zieht. Der Ein- / Aus-Schalter unterbricht nur die Gleichspannung hinter dem eingebauten Netzteil.
Paralleltype zum Grundig C4500 Automatic
- Net weight (2.2 lb = 1 kg)
- 3.8 kg / 8 lb 5.9 oz (8.37 lb)
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
