• Country
• France

• Manufacturer / Brand
• Mondial, Société (Mondial Radio); Paris

• Year
• 1936/1937 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 328090

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 6D6 75 A2543 25Z5

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: 37 - Mondial, Société Mondial Radio

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 358 x 444 x 260 mm / 14.1 x 17.5 x 10.2 inch

• Notes

• Gerät ohne Tonblende

• Author
• Model page created by Philippe Bopp. See "Data change" for further contributors.
