C359 avec oeil magique
Monopole, Bouveau et Cie; Paris, Montreuil-sous-Bois
- Country
- France
- Manufacturer / Brand
- Monopole, Bouveau et Cie; Paris, Montreuil-sous-Bois
- Year
- 1938/1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 100237
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 458 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 130; 220; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch
- Power out
- 2.6 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: C359 [avec oeil magique] - Monopole, Bouveau et Cie;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 530 x 335 x 270 mm / 20.9 x 13.2 x 10.6 inch
- Notes
-
3 gammes d'ondes : OC de 18 à 50 m, PO de 200 à 500 m, GO de 1000 à 1900 m. Anti-fading. Réglage de tonalité. Prises de pick-up et HP supplémentaire. Lampes cadran : 3 x 7 V / 0.3 A.
Existe aussi comme modèle spécial 25 périodes, supplément 2%.
Ébénisterie palissandre verni, décor cuivre.
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Price in first year of sale
- 2,175.00 FRF
- Circuit diagram reference
- La Documentation du Revendeur - Radio
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
