Inconnu - Unknown 1
Monopole, Bouveau et Cie; Paris, Montreuil-sous-Bois
- Country
- France
- Manufacturer / Brand
- Monopole, Bouveau et Cie; Paris, Montreuil-sous-Bois
- Year
- 1933 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 250826
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 22 cm = 8.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Inconnu - Unknown 1 - Monopole, Bouveau et Cie;
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 520 x 430 x 260 mm / 20.5 x 16.9 x 10.2 inch
- Notes
-
L'appareil présenté ici est probablement un radio-phono (voir le haut du coffret avec découpure). Le châssis peut être K36AF.
Le jeu de lampes n'est pas certain.
- Author
- Model page created by Jacky Parmentier. See "Data change" for further contributors.
