• Country
• Austria

• Manufacturer / Brand
• Morawetz; Salzburg

• Year
• 1928 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 155731

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• A409 L410

• Main principle
• TRF with regeneration; 1 AF stage(s)

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries / 100 & 4 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Little Casting 2 Röhren - Morawetz; Salzburg

• Shape
• Tablemodel, slant panel.

• Dimensions (WHD)
• 380 x 190 x 190 mm / 15 x 7.5 x 7.5 inch

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Literature/Schematics (1)
• - - Data from my own collection

• Author
• Model page created by Josef Loidl. See "Data change" for further contributors.
