NC-57

National Company; Cambridge & Malden (MA)

Données

Forum

Images

Collections

Pays
Etats-Unis

Fabricant / Marque
National Company; Cambridge & Malden (MA)

Année
1947–1951

Catégorie
Récepteur amateur (bandes amateurs, ev. avec bande AM)

Radiomuseum.org ID
49602

- alternative name: National Toy Co.
- Brand: Thrillbox

Images
Schémas

NC-57; National Company; (ID = 350792) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350793) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350794) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350795) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350796) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350797) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350798) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350799) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350800) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350801) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350802) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350803) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350804) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350805) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350806) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 350807) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417272) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417273) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417274) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417275) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417276) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417277) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417278) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 1417279) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 2685883) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 3056193) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 3056194) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 3056195) Amateur-R — National Company; NC-57 (3)

NC-57; National Company; (ID = 2756050) Amateur-R — National Company; NC-57 (1)
National NC-57

NC-57; National Company; (ID = 2756051) Amateur-R — National Company; NC-57 (1)
NC-57 bottom view with all new capacitors

NC-57; National Company; (ID = 267145) Amateur-R — National Company; NC-57 (2)
By courtesy of William Kendrick, USA

NC-57; National Company; (ID = 1116857) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 1116858) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 1116859) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 1116863) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 1116864) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 1116865) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 1116866) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 1417271) Amateur-R — National Company; NC-57 (2)

NC-57; National Company; (ID = 2049286) Amateur-R — National Company; NC-57 (1)

NC-57; National Company; (ID = 2049287) Amateur-R — National Company; NC-57 (1)

NC-57; National Company; (ID = 2754805) Amateur-R — National Company; NC-57 (2)
Allied Radio catalog ad for the NC-57

NC-57; National Company; (ID = 2754806) Amateur-R — National Company; NC-57 (2)

Cliquez sur la vignette du schéma pour le demander en tant que document gratuit.

Spécifications techniques

No. de tubes
8

Lampes / Tubes
6SG7 6SB7Y 6SG7 6SG7 6H6 6SL7GT 6V6GT 5Y3GT 0D3

Principe général
Super hétérodyne avec étage HF; FI/IF 455 kHz

Gammes d'ondes
PO et plus que 2 x OC

Tension / type courant
Alimentation Courant Alternatif (CA) / 105-130 Volt

Haut-parleur
HP dynamique à aimant permanent + bobine mobile / Ø 5 inch = 12.7 cm

Puissance de sortie
1.5 W (qualité inconnue)

Matière
Boitier métallique

De Radiomuseum.org
Modèle: NC-57 - National Company; Cambridge &

Forme
Modèle de table générique

Dimensions (LHP)
419 x 298 x 222 mm / 16.5 x 11.7 x 8.7 inch

Remarques
coverage 540 - 55000 kHz, AM, CM (BFO);
optional external S-Meter SM-57, optional 6V DC power supply NC-686S, optional select-o-ject

Poids net
14 kg / 30 lb 13.4 oz (30.837 lb)

Prix de mise sur le marché
90.00 $

Source extérieure
Ernst Erb

Source
Communications Receivers

Source du schéma
Rider's Perpetual, Volume 18 = 1949 and before

Littérature
Shortwave Receivers - Past & Present (3rd ed.)

Schémathèque (1)
Photofact Folder, Howard W. SAMS (Set 48, Folder 14)
