- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1954 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 333675
leboncoin.fr #2066461223 seller Morice
leboncoin.fr #2066461223 seller Morice
leboncoin.fr #2066461223 seller Morice
leboncoin.fr #2066461223 seller Morice
by courtesy of Ever Ondia , collector France
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- Selengleichrichter
- Main principle
- Superheterodyne (common); Export model
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 7003 - Nordmende, Norddeutsche Mende-
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 482 x 317 x 250 mm / 19 x 12.5 x 9.8 inch
- Notes
-
Nordmende 7003 ist ein Exportmodell für Portugal/Spanien. Es ist äusserlich dem Modell Oberon 55 sehr ähnlich.
Wellenbereiche:
- SW 1 = 60, 75 und 90 m Band
- SW 2 = 16, 19, 25, 31, 41 und 49 m Band
- BC (MW) = 515 - 1750 kHz
Röhrenbestückung teilweise unsicher.
