Erdungsmesser 1805 28303/2384298
NORMA Messtechnik GmbH; Wien
- Country
- Austria
- Manufacturer / Brand
- NORMA Messtechnik GmbH; Wien
- Year
- 1968 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 255829
Picture courtesy of guest James Greene
Picture courtesy of guest James Greene
Picture courtesy of guest James Greene
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / 3R12: 2 x 4,5 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Erdungsmesser 1805 28303/2384298 - NORMA Messtechnik GmbH; Wien
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 220 x 115 x 130 mm / 8.7 x 4.5 x 5.1 inch
- Net weight (2.2 lb = 1 kg)
- 2.2 kg / 4 lb 13.5 oz (4.846 lb)
- External source of data
- Information courtesy of guest James Greene
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
