• Country
• Austria

• Manufacturer / Brand
• NORMA Messtechnik GmbH; Wien

• Year
• 1952

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 195399

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• EF40 EF40

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Tonfrequenz-Röhrenvoltmeter 367 - NORMA Messtechnik GmbH; Wien

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 130 x 215 x 110 mm / 5.1 x 8.5 x 4.3 inch

• Notes

• Norma Tonfrequenz-Röhrenvoltmeter 367;
  10 Meßbereiche: 10-30-100-300 mV, -1-3-10-30-100-300 V, 30 Hz - 30 kHz
  Kleinste meßbare Spannung: 0,2 mV

  Ri = 1,5 MΩ in allen Meßbereichen
  Ci = 35 pF im Bereich 10 mV
  Ci = 20 pF in allen anderen Bereichen

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• Mentioned in
• Radiotechnik-Radioamateur (RT), Erb, Wien (47) (Heft 3, März 1952 S.104 Werbeschaltung)

• Literature/Schematics (1)
• Werkzeug und Maschine, Jänner 1952, Seite 21

• Author
• Model page created by a member from A. See "Data change" for further contributors.
