Le Yacht
Océanic, ITT Océanic; Paris
- Country
- France
- Manufacturer / Brand
- Océanic, ITT Océanic; Paris
- Year
- 1959/1960
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 128386
radio portatile della mia collezione
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 2 × 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Le Yacht - Océanic, ITT Océanic; Paris
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 270 x 200 x 90 mm / 10.6 x 7.9 x 3.5 inch
- Notes
-
2 gammes d'ondes. 6 transistors + 2 diodes. Antenne cadre incorporé. Prise antenne-auto.
Le Yacht est le version 2 gammes du Croisière. Un modèle Croisière avec 2 gammes d'ondes très probablement n'existe pas : la seule indication de son existence sont diverses publicités qui ne sont pas concluants. Voir le texte sur Croisière.
- Net weight (2.2 lb = 1 kg)
- 2 kg / 4 lb 6.5 oz (4.405 lb)
- Mentioned in
- - - Manufacturers Literature (Tarif Radio N. 360, 1960)
- Literature/Schematics (2)
- -- Original prospect or advert
- Author
- Model page created by Eddy Rischmann. See "Data change" for further contributors.
