Triple Voltage Power Supply LABPAC B602D/S

Oltronix AB; Vällingby

Data
Forum
Pictures
Collections

  • Year
  • 1979 ?
  • Category
  • Power supply/conditioner or battery or charger
  • Radiomuseum.org ID
  • 247436

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • none
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Triple Voltage Power Supply LABPAC B602D/S - Oltronix AB; Vällingby
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 176 x 176 x 255 mm / 6.9 x 6.9 x 10 inch
  • Notes

  • NEW triple voltage power supply with DIGITAL SETTING
    • Output 1 : 0 - 30 V at 1.4 A
      Output 2: 0 - 30 V at 1.4 A
      Output 3: 5 V at 1 A

    • The output voltages are fully independent and separated from each other. The isolation voltage among them and against the instrument case is ±500 V DC and may be applied for continuous operation

    • DIGITAL SETTING and readout of the output voltages with an accuracy of ±0.3% by means of a 10-turn precision potentiometer. This, in many cases, is a valid substitute for an extra DVM measuring the output voltage

    • Adjustable current limits from 5% to 105% of the nominal current

    • Low source and load effect, low PARD (ripple and noise)

    • Short circuit protected

    • Switchable volt/ampere-meters

    • Operating mode indicated by LED's: constant voltage or constant current

    • Mains transformer with overtemperature protection (OTP)

  • Net weight (2.2 lb = 1 kg)
  • 5 kg / 11 lb 0.2 oz (11.013 lb)
