- Country
- France
- Manufacturer / Brand
- Ondia (Le Matériel); Boulogne-sur-Mer, Paris
- Year
- 1951
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 68482
-
- alternative name: Le Matériel Ondia - see Ondia
Dépliant Ondia
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 90 - Ondia Le Matériel; Boulogne-
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 400 x 250 x 200 mm / 15.7 x 9.8 x 7.9 inch
- Notes
-
4 gammes d'ondes dont 1 bande étalée (BE) de 49 à 50 m.
Ébénisterie galbée en noyer avec grilles plastique ivoire et or.
- Net weight (2.2 lb = 1 kg)
- 5.3 kg / 11 lb 10.8 oz (11.674 lb)
- Price in first year of sale
- 23,950.00 FRF
- External source of data
- Serge Laffont/Martin Renoth
- Mentioned in
- -- Original prospect or advert
- Literature/Schematics (2)
- Radio Constructeur et Dépanneur (No 76, février 1952, p.65)
