- Country
- France
- Manufacturer / Brand
- Pathé-Marconi, Les IME (I.M.E.), La Voix de son Maître; Paris
- Year
- 1955 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 132999
-
- alternative name: La Voix de son Maître
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- ECC81 ECC84 6BM5 EBF80 EF85 EF80 EF80 EF80 EL84 6AB8 ECL80 EY81 EL81 EY86 GZ32 MW43-22
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 1037 - Pathé-Marconi, Les IME I.M.E.,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 540 x 480 x 480 mm / 21.3 x 18.9 x 18.9 inch
- Notes
- 1037 Pathé Marconi est un TV NB bandes VHF UHF. Il a été produit à l'usine de Chatou (Seine et Oise).
- Author
- Model page created by Jacky Parmentier. See "Data change" for further contributors.
