• Country
• France

• Manufacturer / Brand
• Marconi (marque), Cie. Fse. du Gramophone; Paris

• Year
• 1940 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 310424

• Number of Tubes
• 6

• Valves / Tubes
• ECH3 EF9 EBF2 6V6G EM1 5Y3

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 49 Ch= 640 - Marconi marque, Cie. Fse. du

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 520 x 330 x 270 mm / 20.5 x 13 x 10.6 inch

• Notes

• Équivalent au Pathé 640.

• Author
• Model page created by Philippe Ragot. See "Data change" for further contributors.
