• Country
• France

• Manufacturer / Brand
• Radio Perfecta; Saint-Max, Nancy

• Year
• 1950 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 130539

• Number of Tubes
• 6

• Valves / Tubes
• ECH42 EAF42 EF41 EL41 EM34 EZ40

• Main principle
• Superheterodyne (common); ZF/IF 480 kHz

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Inconnu - Unknown 1 - Radio Perfecta; Saint-Max,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 480 x 240 x 300 mm / 18.9 x 9.4 x 11.8 inch

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Mentioned in
• Le grand livre de la TSF (Doctsf Ref 17297)

• Author
• Model page created by Eddy Rischmann. See "Data change" for further contributors.
