Le Moineau alternatif
Phénix, Lavalette-Phénix; Saint-Maur, Paris
- Country
- France
- Manufacturer / Brand
- Phénix, Lavalette-Phénix; Saint-Maur, Paris
- Year
- 1957
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 111364
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 125; 145; 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 cm = 4.7 inch
- Material
- Metal case
- from Radiomuseum.org
- Model: Le Moineau [alternatif] - Phénix, Lavalette-Phénix;
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 300 x 215 x 110 mm / 11.8 x 8.5 x 4.3 inch
- Notes
-
4 gammes d'ondes dont 1 bande étalée. Cadran lumineux.
Entourage metallique, décor et pied plastique, se fait en differents coloris.
- Literature/Schematics (1)
- Le grand livre de la TSF (Doctsf Ref 1139 (année 1959))
- Literature/Schematics (2)
- -- Original prospect or advert
- Author
- Model page created by Georges Van Campenhout † 28.4.22. See "Data change" for further contributors.
