48-1000-5 code 122

Philco, Philadelphia Stg. Batt. Co.; USA

Datos
Foro
Imágenes
Colecciones

  • Año
  • 1948
  • Categoría
  • Televisión (TV) o monitor
  • Radiomuseum.org ID
  • 164471

Haga clic en la miniatura esquemática para solicitarlo como documento gratuito.

 Especificaciones técnicas

  • Numero de valvulas
  • 27
  • Principio principal
  • Superheterodino en general; ZF/IF 26600/22100 kHz
  • Gama de ondas
  • Bandas de recepción puestas en notas.
  • Tensión de funcionamiento
  • Red: Corriente alterna (CA, Inglés = AC) / 105-125 Volt
  • Altavoz
  • Altavoz dinámico (de imán permanente) / Ø 6 inch = 15.2 cm
  • Potencia de salida
  • 2.5 W (unknown quality)
  • Material
  • Madera
  • de Radiomuseum.org
  • Modelo: 48-1000-5 code 122 - Philco, Philadelphia Stg. Batt
  • Forma
  • Sobremesa de cualquier forma, detalles no conocidos.
  • Anotaciones
  • Philco 48-1000-5;
    10" round CRT b/w TV with 12 channel US FCC standard VHF turret tuner, 50 Hz mains power supply model!

    The Philco model 48-1000 television was introduced in 1947. It has an 8-channel turret tuner with plug-in coils, so that any 8 of the available channels 1-13 could be selected. A unique design feature is a dual 300 ohm antenna input, intended for separate antennas for the VHF low and VHF high bands.

    Three chassis codes were used in the following chronological order: code 121, code 125, and code 122. Codes 121 and 125 are similar, both having 26 tubes. In code 122, the 1N34 crystal diode DC restorer was replaced with a 6AT6 tube, bringing the tube count to 27.

    Philco had other TV models with similar chassis. Model 48-1050 was a console version of the 48-1000, with the same three available chassis codes. Model 48-1001 is another table model electrically identical to 48-1000 code 122, but has a simpler cabinet style. Models 48-1000-5, 48-1050-5, and 48-1001-5 have power supplies designed for 50 Hz AC supply, but are otherwise identical to the models without the -5 suffix. Model 48-2500 is a large console projection set with a chassis based on the 48-1000 design, but with several significant changes to support the projection CRT system.
  • Precio durante el primer año
  • 395.00 $
  • Documentación / Esquemas (1)
  • Rider TV Philco 2-42
  • Autor
  • Modelo creado por un miembro de A. Ver en "Modificar Ficha" los participantes posteriores.
