11GF129 /01F
Philips France; Paris
- Country
- France
- Manufacturer / Brand
- Philips France; Paris
- Year
- 1968
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 331638
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
- Power out
- 2.5 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: 11GF129 /01F - Philips France; Paris
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 410 x 145 x 260 mm / 16.1 x 5.7 x 10.2 inch
- Notes
-
Tourne-disques 4 vitesses, similaire au GC029. Tête de lecture stéréophonique GP300. HP inversé type AD3721SX, Z = 8 ohms. Prise pour stéréophonie.
Coffre bois gainé deux tons.
- Net weight (2.2 lb = 1 kg)
- 5.2 kg / 11 lb 7.3 oz (11.454 lb)
- Mentioned in
- -- Original-techn. papers. (Année 1968)
- Author
- Model page created by Toni Gutiérrez García. See "Data change" for further contributors.
