• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1967 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 229215

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH81 EBF89 ECL86 EM87

• Number of Transistors
• 2

• Semiconductors
• AF124 AF125

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Wired Wireless Receiver (RF!)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1.5 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 22RB371 /16 - Philips - Österreich

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 500 x 175 x 165 mm / 19.7 x 6.9 x 6.5 inch

• Notes

• Fertigung für die Schweiz.

  Siehe auch ähnliches Modell Radiola RA3231A.

• Author
• Model page created by Manfred Fries. See "Data change" for further contributors.
