• Country
• Sweden

• Manufacturer / Brand
• Philips, Svenska AB, Stockholm

• Year
• 1978/1979 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 190038

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 28

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• 4 Loudspeakers / Ø 4 inch = 10.2 cm

• Power out
• 2 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 780 22AH780 /22 - Philips, Svenska AB, Stockholm

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 230 x 230 x 220 mm / 9.1 x 9.1 x 8.7 inch

• Notes
• Kompakt-System mit integriertem HiFi Steuergerät in einer LS Box.
  Wellenbereiche UKW und MW.
  5 UKW Stationstasten.
  Phono und Tape Eingänge 2x15W Sinus Ausgangsleistung.
  Boxen mit jew. 4" Bass und 2" Hochton Chassis bestückt.

• Price in first year of sale
• 698.00 DM

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Heinrich Stummer. See "Data change" for further contributors.
