B3S12A

Philips, Svenska AB, Stockholm

Data
Forum
Pictures
Collections

  • Year
  • 1963 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 341743

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 468/10850 kHz; 2 AF stage(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: B3S12A - Philips, Svenska AB, Stockholm
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 360 x 192 x 185 mm / 14.2 x 7.6 x 7.3 inch
  • Notes

  • Das Model "Philips B3S12A" ist technisch sehr ähnlich dem Philips B3S22A. Unterschiede zeigt die Gehäusefront. Philips B3S22A ist mit Stoff verblendet, Philips B3S12A mit Kunststofflamellen.


  • Net weight (2.2 lb = 1 kg)
  • 3.850 kg / 8 lb 7.7 oz (8.48 lb)
  • Author
  • Model page created by Joachim Benneke. See "Data change" for further contributors.
