B3F80A
Philips France; Paris
- Country
- France
- Manufacturer / Brand
- Philips France; Paris
- Year
- 1958
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 139265
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: B3F80A - Philips France; Paris
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 330 x 220 x 165 mm / 13 x 8.7 x 6.5 inch
- Notes
-
4 gammes d'ondes : GO de 1100 à 1950 m, PO de 185 à 572 m, OC de 16.5 à 48.5 m, et BE (bande étalée) de 47 à 51 m. Cadre ferrite et antenne OC incorporés.
Coffret moulé coloris bordeaux, ivoire ou anthracite.
Modèle prévu pour le montage d'un adaptateur chalutier FD 002 79 (gamme de 80 à 200 m), commutation en enfonçant les touches PO et OC.
Équivalent au Radiola RA379A.
- Net weight (2.2 lb = 1 kg)
- 5.080 kg / 11 lb 3 oz (11.189 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Fabio Zannier. See "Data change" for further contributors.
- Other Models
-
Here you find 616 models, 553 with images and 335 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
