• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1960 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 250610

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• OC58 AC126 OC75 OC74 OC74 OC74 AC128 AC127

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Special Tape or Cassette-Format

• Power type and voltage
• Batteries / addl. power jack / 6 x 1.5 Volt

• Loudspeaker
• - This model requires external speaker(s). / Ø 6.5 cm = 2.6 inch

• Power out
• 0.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Batterie-Diktiergerät EL3583 - Philips - Österreich

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 200 x 65 x 170 mm / 7.9 x 2.6 x 6.7 inch

• Notes

• Diktiergerät mit Spezialkassetten.
  Wiedergabe über das Mikrofon.

  Siehe auch Batterie-Diktiergerät (mit 9 Transistoren) EL 3583 /00

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
