BF336A /25
Philips France; Paris
- Country
- France
- Manufacturer / Brand
- Philips France; Paris
- Year
- 1954/1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 238451
Dépliant Série Super-Magnétique 1955
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
- Power out
- 1.6 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: BF336A /25 - Philips France; Paris
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 370 x 270 x 171 mm / 14.6 x 10.6 x 6.7 inch
- Notes
-
4 gammes d'ondes : BE (bande étalée) de 47 à 50.8 m, OC de 16.5 à 51 m, PO de 185 à 572 m, et GO de 1100 à 1950 m. Cadre ferrocapteur semi-orientable et plaque antenne OC incorporés. Tonalité à 2 positions. HP type 1630X ( Z = 5 ohms). Prise pick-up.
Coffret polystyrène 2 couleurs: bordeaux, ivoire.
Modèle pour 25 périodes, version 50 périodes voir BF336A.
Documentation de base voir modèle BF331A.
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (2)
- -- Original prospect or advert (Dépliant Série Super-Magnétique 1955)
