Colosseum 24 Automatic A24T694 /00 /02 Ch= F6
Philips - Österreich
- Country
- Austria
- Manufacturer / Brand
- Philips - Österreich
- Year
- 1970
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 112160
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Number of Transistors
- 18
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Colosseum 24 Automatic A24T694 /00 /02 Ch= F6 - Philips - Österreich
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 655 x 485 x 265 mm / 25.8 x 19.1 x 10.4 inch
- Notes
-
Empfangsbereiche VHF und UHF.
Zwei Ausführungen:
/00 = dunkel Hochglanz;
/02 = Nuß matt.Zwei Chassisausführungen, siehe Schaltpläne.
Parallelgerät zum Horny W61T396.
- Net weight (2.2 lb = 1 kg)
- 25 kg / 55 lb 1.1 oz (55.066 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
