• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1968

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 111996

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• EF183 PCF200 PCL84 PCL86 PL84 PCH200 PCF802 PCL805 PL504 PY88 DY802 A59-23W

• Number of Transistors
• 8

• Semiconductors
• AF239 AF239 AF139 BF173 AF126 BF115 AC125 AC132

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Colosseum A23T643 /00 Ch= F4-KÄ - Philips - Österreich

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 700 x 500 x 560 mm / 27.6 x 19.7 x 22 inch

• Notes
• Empfangsbereich VHF + UHF.

• Net weight (2.2 lb = 1 kg)
• 25 kg / 55 lb 1.1 oz (55.066 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Wolfgang Bauer. See "Data change" for further contributors.
