Compact Stereo kombi total 22AH960

Philips - Österreich

  • Year
  • 1977
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 123163

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Alternating Current supply (AC) / 127; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 8 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Compact Stereo kombi total 22AH960 - Philips - Österreich
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 508 x 107 x 338 mm / 20 x 4.2 x 13.3 inch
  • Notes
  • Stereo-Steuergerät mit eingebautem Kassettenrecorder N2503.
    Phono Laufwerk 22GC014
    2 Lautsprecherboxen 22AH461/21R im Lieferumfang.
