E151A

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Philips Electrical, Lamps, Industrial - Miniwatt; London

• Year
• 1940–1943

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 116145

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• EF50 ECH35 EF39 EBC33 EL33 DW4/350

• Main principle
• Superhet with RF-stage; ZF/IF 465 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 105; 120; 210; 230; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: E151A - Philips Electrical, Lamps,

• Shape
• Tablemodel, with any shape - general.

• Notes

• Coverage:
  MW 198...565 m (1515...531 kHz)
  SW 48...150 m (6,2...20 MHz)
  SW bandspread circuits:
  13 m, 16 m, 19 m, 25 m, 31 m, 41 m.
  Only in SW bandspread mode, the EF50 acts as a rf preamplifier with an untuned (aperiodic) input circuit.
  Scale lamps 3x 6,2V/0,3A.
