Miniphon 113 22GF113
Philips - Österreich
- Country
- Austria
- Manufacturer / Brand
- Philips - Österreich
- Year
- 1972
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 81949
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Line / Batteries (any type) / 110; 127; 220; 240 / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Miniphon 113 22GF113 - Philips - Österreich
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 335 x 220 x 115 mm / 13.2 x 8.7 x 4.5 inch
- Notes
- Plattenspieler mit 33 / 45 / 78 U/min
2 Ausführungen:
/03E = gelb
/03F = grün
Tonkopf GP 204
- Source of data
- -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
