Maestro 4416 N4416 /00 /15 /19 /43
Philips - Österreich
- Country
- Austria
- Manufacturer / Brand
- Philips - Österreich
- Year
- 1972–1975
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 28870
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 10 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Maestro 4416 N4416 [/00 /15 /19 /43] - Philips - Österreich
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 515 x 380 x 200 mm / 20.3 x 15 x 7.9 inch
- Notes
- Vierspur-HiFi-Stereo; Bandgeschwindigkeiten: 4,75/9,5/19 cm/s; Spulen-Ø: 18 cm; Übertragungsbereich bei 19 cm/s: 40-20000 Hz; NF-Verstärker mit 2 Endstufen je 5 W.
4 Ausführungen: /00, /15, /19, /43.
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- External source of data
- Erb
- Source of data
- Handbuch VDRG 1972/1973 / Radiokatalog Band 2, Ernst Erb
- Literature/Schematics (1)
- -- Original-techn. papers.
