Microvoltmètre pour tension continue PM2440
Philips France; Paris
- Country
- France
- Manufacturer / Brand
- Philips France; Paris
- Year
- 1965 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 244170
Imagen del manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Number of Transistors
- 2
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 240 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Microvoltmètre pour tension continue PM2440 - Philips France; Paris
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 360 x 240 x 220 mm / 14.2 x 9.4 x 8.7 inch
- Notes
-
Le microvoltmètre PM 2440 est un appareil de mesure électronique très sensible qui perment de mesurer des tensions continues provenant de sources à impédance élevée et également des très faibles intensités de courant.
- Net weight (2.2 lb = 1 kg)
- 10.1 kg / 22 lb 3.9 oz (22.247 lb)
- Literature/Schematics (2)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
- Other Models
-
Here you find 617 models, 555 with images and 335 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
