Minauto Box 11RN262
Philips France; Paris
- Country
- France
- Manufacturer / Brand
- Philips France; Paris
- Year
- 1966/1967
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 331743
Hersteller-Doku
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 1.2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Minauto Box 11RN262 - Philips France; Paris
- Shape
- Chassis only or for «building in»
- Notes
-
Récepteur autoradio monobloc, HP type FH 3409 RX incorporé.
- Mentioned in
- -- Original-techn. papers. (Saison 1966-1967)
- Author
- Model page created by Toni Gutiérrez García. See "Data change" for further contributors.
