NG1415
Philips - Österreich
- Country
- Austria
- Manufacturer / Brand
- Philips - Österreich
- Year
- 1968
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 83859
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 29
- Main principle
- Superhet with RF-stage; ZF/IF 10850 kHz
- Tuned circuits
- 10 FM circuit(s)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 17 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: NG1415 - Philips - Österreich
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 520 x 98 x 250 mm / 20.5 x 3.9 x 9.8 inch
- Notes
- Laut techn. Dokumentation beträgt die Ausgangsleistung 2x 17 W an 4 Ohm. Das kann nicht stimmen da die maximale Leistungsaufnahme des Gerätes bei 40 Watt liegt. Richtig ist 17 W Gesamt-Ausgangsleistung.
Sendermemomatic, abschaltbare AFC.
Ausgangsimpedanz: 4...8 Ohm.
Jeder Transistortyp nur einmal gelistet.
- Net weight (2.2 lb = 1 kg)
- 6 kg / 13 lb 3.5 oz (13.216 lb)
- Source of data
- -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb
