Philetta 203U
Philips Belgium (Belgien)
- Country
- Belgium
- Manufacturer / Brand
- Philips Belgium (Belgien)
- Year
- 1941/1942
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 272119
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- AC/DC-set / 110; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Philetta 203U - Philips Belgium Belgien
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 270 x 160 x 130 mm / 10.6 x 6.3 x 5.1 inch
- Notes
-
See also Philetta 203U manufactured by Philips Eindhoven.
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
- Other Models
-
Here you find 587 models, 563 with images and 341 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Philips Belgium (Belgien)
Collections
The model Philetta is part of the collections of the following members.
Forum contributions about this model: Philips Belgium: Philetta 203U
Threads: 1 | Posts: 5
I'm hoping someone has the specs for the neon bulb that was in this set. The original socket in mine is missing. Did the original bulb have threads, bayonet, or did it solder in? The schematic calls for a 7121D on the 203U and a Z10 on the 208U.
Best regards and thank you,
Donald
Donald Cochrane, 23.Feb.23
